VPT
VPT develops high-reliability DC-DC converters, point-of-load modules, EMI filters, and input-protection solutions for space, military, and avionics electronic systems. Its portfolio spans low-voltage point-of-load regulation, wide-input COTS converters, and radiation-hardened space-power families. TARGET A.Ş. is the local technical point of contact in Türkiye for power-budget analysis, product-level selection, and system integration.
Front-end modules that condition platform power against transient, surge, and conducted-interference requirements.
A layer of isolated DC-DC and point-of-load converters that generates the voltages required by each load.
Converter families with product-specific TID, SEE, and quality levels defined for the space environment.
Three complementary families from input protection to the space power rail.
Input voltage, output power, isolation, EMI, temperature, radiation, and quality level are evaluated together to establish the appropriate power chain.
DVMN28 input-protection module
A front-end solution used with DV200-series converters that combines EMI filtering and voltage-transient suppression in one module.
- 28 V nominal input architecture
- EMI filtering and transient suppression
- System pairing with the DV200 series
DVPL0520S POL converter
A synchronous, regulated, non-isolated buck converter for low-voltage point-of-load rails, with power sequencing and fast transient response.
- 5 V nominal input and 20 A output
- 0.8–3.4 V adjustable output
- −55 °C to +125 °C operating range
SGRB space DC-DC family
A radiation-hardened isolated-converter family for high-power space applications, using GaN technology and an integrated EMI filter.
- 100 krad(Si) TID family scope
- 85 MeV/mg/cm² SEE family scope
- Integrated EMI filter and 400 W-class options
Power architecture
From platform input to regulated load rails.
VPT product selection addresses input environment, EMI and transient protection, primary DC-DC conversion, and point-of-load regulation within one power budget.
01 / ENVIRONMENT
Define the mission and power environment
Specify input voltage, transients, temperature, radiation, quality level, and platform standard.
02 / POWER
Calculate conversion stages
Map output voltages, total power, load transients, efficiency, and isolation requirements into the power tree.
03 / FILTER
Match EMI and input protection
Select a compatible filter or transient-suppression module according to the applicable standard’s test conditions.
04 / VERIFY
Validate thermal and electrical margins
Check derating, thermal mounting, startup sequencing, stability, and environmental qualification for each selected part.
Why VPT?
VPT provides complementary product families spanning front-end filtering, point-of-load regulation, and space-grade power conversion.
Complete power-chain approach
EMI filters, input-protection modules, isolated DC-DC converters, and POL products can be matched as a system.
Application-specific product levels
Different screening, quality, and radiation levels are selected at product level for military, avionics, and space requirements.
Selection verified by technical values
Voltage, power, temperature, TID, SEE, and filter compatibility are verified in the current datasheet for the selected model.
DC-DC power solutions for military, avionics, and space
VPT develops high-reliability isolated DC-DC converters, point-of-load regulators, EMI filters, and transient-protection modules. These product families cover different layers of a distributed power architecture, from platform input to low-voltage load rails.
The appropriate solution is selected by evaluating input and output voltages, power budget, isolation, efficiency, transients, conducted EMI, operating temperature, radiation environment, and quality level together.
VPT product selection and integration support in Türkiye
TARGET A.Ş. provides local technical support in Türkiye for VPT power-product requirement analysis, converter and filter matching, power-tree design, thermal mounting, and system integration. Certification, radiation, and environmental qualifications are verified only against the current datasheet for the selected product series.
